2 Spindle HDPE Wire Harness Braiding Machine With Yarn Broken Sensor

Product Categories
Shanghai Qi Pang Industrial Co., Ltd.
Contact Now

2 Spindle HDPE Wire Harness Braiding Machine With Yarn Broken Sensor

  • 1
  • 2

Brand Name : QIPANG

Model Number : QP80/90

Certification : SGS

Place of Origin : Shanghai

MOQ : 1

Price : RMB/USD Negotiable

Payment Terms : T/T, Western Union

Supply Ability : 20/Week

Delivery Time : 1-25 Working Day

Packaging Details : Wooden box

Model : 16/2

Spindle Qty : 2

Head Qty : 2

Dimension(mm) : 1100*700*1700

Power(KW) : 0.75

Horngear size(mm) : 80/90

Max Horngear speed(rpm/min) : 300/320

Bobbin size(mm) : φ43*140/φ48*140

Weight(kg) : 330

Rope dia(mm) : 0.1-8

Contact Now

Polyester PE HDPE Cotton Nylon Dyneema Round Rope Braiding Machine

Suitable material:PP Polyester PE HDPE Cotton Nylon Dyneema etc

Range of products: Gift bag ropes,high tension ropes,fishing lines,safty ropes,fiberglass sleeves,round elastic bands,hollow ropes,core ropes,etc

High speed rope braiding machine is automatic production machine can simple operation. The produced according to customer requirements, Can produce different standard products. The production speed is three times of ordinary braiding machine. The machine parts using real materials, precision design, durable, a low depreciation rate. The high quality machines could create more economic benefits for customers.

1. frequency inverter controlled production speed.

2. braid materials: cotton, PP, polyester, nylon etc.

3. control cabinet & heat treatment

4. yarn broken sensor (if a yarn is broken or a bobbin is empty, the machine stops automatically) .

5. Flat cord braiding machines are focusing on producing flat cord.

6. We also have round cord, specific cord type braiding machines on sale.

7. Except the braiding machines, we also have many other types of textile machines.

Model Spindle Qty Head Qty Dimension(mm) Power(KW) Horngear size(mm) Max Horngear speed(rpm/min) Bobbin size(mm) Weight(kg) Rope dia(mm)
12/4 12 4 980*950*1700 0.75 80/90 300/320 φ43*140/φ48*140 400 0.1-8
16/2 16 2 1100*700*1700 0.75 80/90 300/320 φ43*140/φ48*140 330 0.1-8
16/4 16 4 1080*950*1700 0.75 80/90 300/320 φ43*140/φ48*140 450 0.1-8
16/4 16 4 1780*750*1700 0.75 80/90 300/320 φ43*140/φ48*140 460 0.1-8
24/2 24 2 1250*850*1700 0.75 80/90 300/320 φ43*140/φ48*140 450 0.5-12
32/2 32 2 1370*950*1700 0.75 80/90 300/320 φ43*140/φ48*140 450 1-15
36/2 36 2 1420*980*1700 1.1 80/90 300/320 φ43*140/φ48*140 520 1-15
40/2 40 2 1650*900*1700 1.1 80/90 300/320 φ43*140/φ48*140 550 2-16
48/2 48 2 1850*950*1700 0.75 80/90 300/320 φ43*140/φ48*140 550 2-20

2 Spindle HDPE Wire Harness Braiding Machine With Yarn Broken Sensor

2 Spindle HDPE Wire Harness Braiding Machine With Yarn Broken Sensor2 Spindle HDPE Wire Harness Braiding Machine With Yarn Broken Sensor

2 Spindle HDPE Wire Harness Braiding Machine With Yarn Broken Sensor2 Spindle HDPE Wire Harness Braiding Machine With Yarn Broken Sensor

2 Spindle HDPE Wire Harness Braiding Machine With Yarn Broken Sensor2 Spindle HDPE Wire Harness Braiding Machine With Yarn Broken Sensor
